The ToolkitRC M6DAC Pro is a compact dual-channel charger with an integrated 300W AC power supply. It can be powered from the mains, a DC power source, or an external battery (7–28 V). When powered externally, the charger delivers up to 400 W per channel with a maximum current of 16 A. It supports various battery types including Lipo, LiHV, LiFe, Li-Ion, NiMH, and Pb. The charger can also operate in power supply mode with adjustable voltage and current—ideal for charging smart batteries such as those used by DJI. A USB-C port with 65 W fast charging is available for phones, laptops, or HD cameras. Additionally, the charger supports wireless charging for mobile devices.
You can charge two independent batteries with separate parameters. Each channel delivers up to 400 W. In synchronous mode, both channels can be combined to deliver up to 700 W and 28 A to a single battery. When powered from the mains, output is limited to 200 W due to the internal AC supply.
Control is provided by a metal dial, and all charging data is displayed on a 2.8" IPS screen with 320×240 resolution. The charger features active cooling via a built-in fan.
Do not connect both AC and DC power sources simultaneously.
Key Features
- Power supply: 100-240V AC / 7-28V DC (max 32A)
- Charging power: 300W (AC) / 2×400W 0.1-16A or 1×700W 0.1-28A (DC)
- Battery types: LiPo, LiHV, LiFe, Li-ion, LTO 1-6S, NiMH 1-16S, Pb 1-10S
- Balancing current: 1A
- Balancing accuracy: < 0.005V
- Discharge power: 15W
- Wireless power: 10W
- USB-C: 65W (3.25A @ 20V)
- USB-C protocols: PD3.0/PD2.0/PPS/QC4/QC3.0/QC2.0/AFC/FCP/SCP/PE2.0/PE1.1/SFCP/VOOC
- Size: 116x112x63mm
- Weight: 600g
User Guides
Package Includes
- 1x Charger
- 1x EU Power Cable
