NewBeeDrone AcroBee65 V2 - 1S ELRS Brushed

NewBeeDrone AcroBee65 V2 is a small 1S Tinywhoop with brushed motors, designed especially for beginner pilots. The drone features an integrated AIO board, which combines the flight controller, ESCs, SPI ELRS receiver, and analog video transmitter. Thanks to the AIO design, the drone is lightweight and weighs only 21 grams without the battery. Combined with the propeller guards, it is completely safe to fly.

The core of the flight controller is an F411 processor paired with a BMI270 gyro. The ESCs use N+P MOSFETs, which enable motor reversal. This allows the controller to actively brake the motors, improving motor responsiveness and flight stability. A "Turtle mode" is also available, allowing the drone to flip over if it lands upside down. The integrated ELRS receiver on 2.4GHz ensures long-range control. ELRS is the most widely used RC protocol in the FPV drone community. The built-in analog video transmitter operates on 5.8GHz and supports up to 400mW of output power. The SmartMAX function automatically adjusts power based on temperature. The drone is equipped with brushed motors (6mm, 19700Kv). While less powerful and with a shorter lifespan than brushless motors, they are affordable and great for beginners.

The drone uses a PH2.0 connector. Suitable batteries are 300mAh 1S.

The drone color is shipped randomly.

Betaflight 4.5.1 firmware

The drone can be converted into an RC car
