HGLRC Hammer Dual is a dual antenna designed for 5.8GHz video transmission. It features a construction with two antenna elements, improving link stability and signal coverage compared to standard antennas. The antenna comes with an SMA connector. Total antenna length is 170mm and the weight is approximately 13.8 grams.
RHCP polarization is suitable for analog video transmission, while LHCP polarization is commonly used for digital systems such as Walksnail Avatar or DJI.
Key Features
- Frequency range: 5.35-6GHz
- Gain: 4.4dBi (5.8GHz), 3.1dBi (5.3GHz), 3.75dBi (average)
- VSWR: 1.75 (5.3GHz), 1.17 (5.5GHz), 1.46 (average)
- Cross-Polarization Suppression: -20dB
- Cable: RG141
- Length: 170mm
- Weight: 13.8g
Package Includes
- 1x Antenna
