BetaFPV Pavo20 Pro II O4 Pro - 3S ELRS

Pavo20 Pro II is a small 2.2" Cinewhoop equipped with top-tier DJI O4 Pro digital video transmission with the option to record in up to 4K at 120 fps. The drone is designed primarily for indoor filming or smaller outdoor areas, where it excels with stable image and precise control. Thanks to its low flight weight and ducted propellers, flying the drone is relatively safe. The drone has an integrated ELRS receiver on 2.4GHz.

The drone is based on the BETAFPV F4 2–3S 20A AIO FC V1 AIO board with F405 processor, ICM42688P gyroscope and integrated 20A ESCs. The unit also includes a 9V/2A BEC and 16MB memory for Blackbox. The drone uses LAVA 1104 7200KV motors and Gemfan 2218 3-Blade propellers with a 1,5 mm shaft in combination with a 3S battery. The propeller guards and the DJI O4 Pro unit and camera mount are made of durable PA12 nylon plastic.

The modular frame allows easy replacement of the mount for different video units. Replacement is done without any frame modifications. The camera angle is adjustable and the mount is fitted with rubber softmounts that dampen vibrations.

Thanks to its size, low weight and DJI O4 digital video transmission, the Pavo20 Pro is suitable for detailed indoor flights, shots in small spaces and training precise FPV drone control. The second version has a slightly modified frame.

Suitable batteries are 3S with a capacity of 450–650mAh and an XT30 connector.

Firmware and CLI Dump

Important notice: The DJI O4 camera uses a new generation of gyroscopes that are more sensitive to vibrations. This may affect the proper functionality of RockSteady and Gyroflow stabilization.
